Overviews
The MaxiTPMS TS501 is capable of wirelessly diagnosing TPMS problems as well as activate any known OEM / Universal TPMS sensors, ID clone or reprogram sensors to the vehicle’s ECU, and turn off warning lights.
At-A-Glance TPMS Status Screen
The single screen organization allows you to easily read direct feedback from all 4 sensors, clearly understand the status of all TPMS features,compare sensor and ECU data,then instantly pinpoint system faults to identify the fix.This At-A-Glance view of all sensor information easily shows the location of which sensor battery is low and needs to be replaced soon.
Easy To Use Software Operation
Performing a basic sensor activation or complex diagnostic tool functions, is easy as following the program options and on-screen display instructions. The TS501 provides code definitions and visual / audio responses to make the operations much easier and more convenient to complete.
Download FREE software updates for enhanced diagnostic functions and extended vehicle coverage. Now even your old TPMS tool can perform like new!
OBDII Connected TPMS Diagnostics
The TS501 can provide relearn procedures for specific sensors and connect with the OBDII cord to the vehicle’s ECU to offer multiple programming options including clone sensor IDs, or auto create ID, or manual write sensor IDs with no sensor re-learn required for sensor positioning.
Product Features & Functions:
Programs vehicle ECU to learn sensor IDs and positions
Activates magnetic, frequency and tire deflation triggered sensors using 125 kHz continuous or modulated wave signals
Receives 315 MHz, 433.92 MHz and 309MHz signals
Reads sensor ID from vehicle ECU
Reads/clears codes of TPMS system and resets malfunction indicator light
Built-in rechargeable Li-ion battery
On-screen code definitions
Simplifies the diagnostic process including four and five wheel
vehicles by showing vehicle graphs
Decodes sensor data and provides visual and audible
responses to confirm sensors are working properly
Interprets data including sensor ID, tire pressure, temperature,
battery status and OE part no.
Pre-selection process offers faster activation and diagnostics
Accurate diagnosing results – a tool users can trust
Lifetime free upgrade on the internet via USB port
Easy-to-use with intuitive navigation and step-by-step on-screen
Instruction:
Prints TPMS sensor data via PC
Automatic power-off to preserve battery life
Proper LF signal to prevent being fooled by
other RF signals
Saves up to 16 TPMS records
If a failed sensor is detected, the tool displays
the replacement part number
Vehicle Coverage:
European Vehicle
USA Vehicle
Asia Vehicle
Specifications:
Display:TFT color display (320 x 240 dpi)
Power:3.7V Li-polymer battery
Operating Temperature:0 to 50°C (32 to 122 °F)
Storage Temperature:-20 to 70°C (-4 to 158 °F)
LengthWidthHeight:202.2mm(7.96″)106.7mm(4.20″)37.7mm(1.48″)
Package List:
MaxiTPMS TS501 tool
OBDII cable
Molded plastic case
USB cable
Magnet (For early model TPM sensors)
User manual
Battery
